FCO210 microcalibrator

The FCO210 is designed to be a leak detector equipment calibrator when working on production lines.

The equipment has a small internal laminar flow element to be able to measure small flows and express them in cc/min or cc/hr units.

Flow measurement can vary easily, so the equipment is prepared to compensate for variations in environmental conditions.

Download datasheet

ADVANTAGE

  • Flow measurement range from 2 cc / min to 2000 cc / min
  • Temperature compensation

APPLICATIONS

  • Gauge to check fugometers
  • Leakage simulator for good parts and bad parts

CHARACTERISTICS

  • Works with battery
  • Needle valve for fine adjustment and integrated shut-off valve

DATA SHEET

ELECTRICAL DATAPNEUMATIC DATABUILDING

LEAK MEASURE
Flow range
  • 0-2 cc/min
  • 0-20 cc/min
  • 0-200 cc/min
  • 0-2000 cc/min
  • 0-200 cc/hr
  • 0-2000 cc/hr
  • 0-200 mm3/s
  • 0-2000 mm3/s
Improved accuracy at 20 ºC
  • 10% to 100% range: & lt; ± (1% reading + 1 digit)
  • 0 to 10% range: & lt; ± (0.1% rank + 1 digit)
Resolution 4-digit display
Temperature coefficients
  • Zero: semi-automatic
  • Span: & lt; ± 0.1% per ° C
Long-term drift <1% by year
Supply voltage 9V battery
Battery life More than 250 hours
Work temperature 0 a 50 ºC
Supported media Clean and dry air, non-corrosive gases
Overpressure 20 x range
Pneumatic connection Input 1/8 BSP H, output port M5
Static pressure Vacuum to 14 bar relative
Internal volume 0,8 mm
Box Polycarbonate case with steel base
Dimensions 191 x 168 x 132 mm
Weight 1 kg
